The Eagle & Eagle 250 notchers with a 6.5 horsepower hydraulic motor, offer front to back cutting to hold material against its stop. Both feature a cope, Hi-Carbon, Hi-Chrome blades, an internal stop for shearing, two patented 12 combination horizontal hold down and stop bars, engraved brass scales, a moveable electric foot pedal and a scrap bucket

The Eagle machines are adjustable up to 50 strokes per minute in jog, single or continuous mode. They have a 35 wide by 25 deep table with a milled bed surface so materials do not float or stick. The Eagles capacity is 1/4in for mild steel and 3/16in for stainless steel, with notch widths of 8-7/8in x 8 7/8in for a 90 notch. Choose from a 90 fixed angle or variable angles from 30 to 120.

Additionally, the Eagle 250 offers two material hold downs and a special blade guard.

CLICK TO VIEWBROCHURE

Technical Data

Cutting Capacity	1/4" (3/16")
Cut Length	8-7/8" x 8-7/8"
Cut Angle	90
Machine Weight	1540 lbs
Overall Dimensions	49" x 36" x 53"
Table Dimensions	35" wide by 25"
2nd Station	-
Motor Size	6.5 hp

Boscherts powerful notchers offer superior performance, clean cuts and high accuracy. Enjoy a 90 fixed angle and variable angle from 30-120. The Eagle & Eagle 250 Hydraulic Power Notcher w/Cope offers front to back cutting to hold material against stop, 50 strokes per minute (adjustable), solid state circuitry, and a milled bed surface for no float or stick operation. Capacity is 1/4in mild steel capacity and 3/16in stainless steel capacity, with notch widths of 8-7/8in x 8 7/8in 90 notch. Additionally, the Eagle offers two material hold downs and a special blade guard. Features The Eagle and Eagle 250 1/4 mild steel capacity 3/16 stainless steel capacity 8-7/8 x 8-7/8 90 notch Front to back cutting to hold material against stop Milled bed surface for no float or stick operation 35 wide by 25 deep table with milled surface so material does not float or stick Front to back cutting Hi-Carbon, Hi-Chrome blades Internal stop for shearing Two patented 12 combination horizontal hold down and stop bars Engraved brass scales Moveable electric foot pedal Adjustable stroke, 50 per minute Solid state circuitry Jog, single or continuous mode 6.5 horsepower motor Scrap bucket The Eagle 250 Has These Additional features: Two material hold downs Special blade guard
