The essential basic characteristics of our Quantum S-391-AV Fully-Automatic Band Saw (such as the rigidity of the blade support, the flywheel dimensioning, band saw blade guides, and band stretching) have been extensively studied thoroughly in order to avoid yielding of the band - ultimately increasing the S-391-AV¢â‚¬â„¢s durability above all other band saws of this size in the marketplace, and assists to improve the linearity of the cuts, as well as the cutting time. This unit is equipped with a Variable Speed Inverter and a Vice Pressure Regulator.
Cycle start is obtained by pressing the relevant start button.
The machine performs the following operations during the cutting cycle:
Material Feeding via Step-Feeder.
Vice closing and activation of band motor. (Fixed vice lock.)
Rotation of the blade and delivery of the coolant.
Head/Bow Down Feed until the finishing of the cut.
Feeding carriage will return until the it reaches the programmed location.
Head/Bow Return to initial position. Blade Revolution and Coolant Delivery will stop.
Vice will open.
Options (Options are at an additional cost):
(+$1,000) Equip the Saw with a Top Vertical Support.
(+$30,000) Equip this Saw with a Parts Incline Loader.
Round Tube Cutting Capacities:
Round Tube Cutting at 90° (Straight Cut): 11-3/4¢â‚¬Â
Solid Round Cutting Capacities:
Solid Round Cutting at 90° (Straight Cut): 9¢â‚¬Â
Square Tube Cutting Capacities:
Square Tube Cutting at 90° (Straight Cut): 11-3/4"
Rectangular Tube Cutting Capacities:
Rectangular Tube Cutting at 90° (Straight Cut): 11-3/4¢â‚¬Â x 12-1/2"
Motor Power: 2.2 kW
Cutting Range: 90° Straight Cuts
Cutting Thickness: 1.2 mm (0.047")
Possibility of making ¢â‚¬Å“manual¢â‚¬Â cuts.
Band Saw Weight: 2,450 lbs. (1,110 kg)
Adjustable Stop for cuts of the same size.
Maximum Vice Opening of 320 mm (12.6¢â‚¬Â)
Vice with Device for Swift-Locking for Quick-Vice Approach.
Saw is manufactured with trans-pallet for versatile movement.
This saw can run at 2 different speeds (0-90 Feet per Minute)
Pedestal with chip collection tray and removable tank for coolant.
Blade Size Dimensions: 3200 x 27 x 0.9 mm (125.98" x 1.06" x 0.035")
Electrical Options Available: 220 Volt / 3 Phase, 480 Volt / 3 Phase
0.06 kW Power-Driven Pump for band cooling and 24V Low-Tension Plant.
Vertical rotation on bolt with adjustable tapered bearings without backlash.
Strong band guides with tight stress-raiser bearings and adjustable widia tips.
Band stretching is obtained by electro-mechanical blade tensioner with micro switch.
Accident-preventing devices on the flywheel casing, on the control handle, and on the blade.
Italian Made Band Saw - Parts for our Band Saws are stocked in the U.S.A. at our Quantum Machinery headquarters.
High-capacity band control by two-speed motor and special reducer with bronze gear and tempered and ground worm screw with appropriately Dimensioned Flywheels with Accident-Preventing Devices on the Flywheel Casing, on the Control Handle, and on the Blade.
S-391-AV Band Saw Overall Dimensions: 79" Height x 66" Length x 60" Width without Accessories / 118" Width with Accessories (2000 x 1670 x 1515mm Width without Accessories / 2990mm Width with Accessories)
