Quantum Machinery 6.5 Foot Hydraulic Vertical Cut Shears with CNC Control
Electrical Options:
-
220V / 3PH / 60Hz
-
480V / 3PH / 60Hz
The last generation of NARGESA CNC Vertical cut shears are made of stabilized, welded steel that allows to take on big jobs without deformation.
Cutting Length: 6'-7" / 2030mm
Max. Thickness in Mild Steel: 0.250" / 6.35mm
Max. Thickness in Stainless Steel: 0.150" / 4mm
ADVANTAGES OF VERTICAL CUT INSTEAD OF SWING CUT:
Energetic saving:
Resistance of material in vertical cut is much lower, which becomes a considerable energetic saving.
Cutting quality:
Clean, perfect and accurate cut.
Life of the blades:
The blades wear is almost nule. The life of the blades is 4 times higher than other shearing systems.
Technical Features:
-
Strokes per minute: 10 Strokes. (All length)
-
Independent hydraulic rammers: 10 units.
-
Millimeter squaring arm, 1000mm length.
-
Two 1000mm-millimetered stand arms.
-
Fix cut inclination: 1,75º
-
Driving with safety pedal and emergency stop.
-
Back overture with safety optoelectronic devices.
-
Motor power: 5,5 KW/ 7,5 HP
-
3-Phased tension: 400 V.
-
Hydraulic Pump: 16 liters.
-
Container capacity: 73 liters.
-
Cutting length: 6'-7" / 2030mm.
-
Cutting capacity: 0.250" / 6.35mm in steel (450N/mm2)andy 4mm in S.S.(700N/mm2)
-
CNC back gauge.
-
Digital display.
-
Gauge displacemnt: 700mm.
-
Accuracy and repeatability of positioning from +/- 0,1mm.
-
4-edged lower and upper blades Suitable for stainless steel.
-
Goose neck for cuts with bigger length: 190mm.
-
Cutting area lit up by leds.
-
Thin marking zone for manual cutting.
