Quantum Machinery 12

Quantum Machinery 12" Manual, Pivot-Style Cold Saw (3-1/2" Round Tube Capacity)

Quantum Machinery 14

Quantum Machinery 14" Semi-Auto, Pivot-Style Cold Saw (4-1/4" Round Tube Capacity)

Quantum Machinery 14" Manual, Pivot-Style Cold Saw (4-1/4" Round Tube Capacity)

The Quantum Machinery Macc NEW 350 EDV Manual Cold Saw has a moveable head that swivels 45 degrees left and 90 degrees right. The reduction unit is in an oil bath with a double hinged pin that has an eccentric bush. The NEW 350 EDV Cold Saw is equipped with a dual quick-locking vice and a sliding counter-vice for longitudinal cutting. Has a 0.035kW power-driven pump for band cooling, along with a coolant filter. This unit is also equipped with a Jet Separation System to keep the blade oiled, has a Bar Support Arm, and a Bar Stop. Manual, service tools and steel pedestal come with the machine.

  • 2 Speeds: 40 - 80 R.P.M. (Saw can be equipped with Variable Speed Inverter)

  • Weight: 510 lbs. (231 kg.)

  • Maximum Vice Opening: 4.7¢â‚¬Â (120mm)

  • Overall Dimensions: 58¢â‚¬Â Width x 40¢â‚¬Â Length x 48¢â‚¬Â Height (1475 x 1000 x 1200 mm)

  • The NEW 350 EDV is to be equipped with a 350 x 2.5 x 32mm Bore HSS Blade

Options (Options are at an additional cost):

  • (+$500) Equip the NEW 350 EDV with Air Vice

  • (+$1,600) Equip the NEW 350 EDV with a Variable Speed Inverter

$4,450.00
SKU
NEW 350 EDV

NEW 350 EDV COLD SAW CUTTING CAPACITIES:

Round Tube Cutting Capacities:

  • Round Tube Cutting at 90° (Straight Cut): 4-1/4"

  • Round Tube Cutting at 45° Right: 3-1/8"

  • Round Tube Cutting at 45° Left: 3-1/8"

Square Tube Cutting Capacities:

  • Square Tube Cutting at 90° (Straight Cut): 3-7/8"

  • Square Tube Cutting at 45° Right: 3-1/8"

  • Square Tube Cutting at 45° Left: 3-1/8"

Solid Round Cutting Capacities:

  • Solid Round Cutting at 90° (Straight Cut): 2-1/4"

  • Solid Round Cutting at 45° Right: 2-1/8"

  • Solid Round Cutting at 45° Left: 2-1/8"

Rectangular Tube Cutting Capacities:

  • Rectangular Tube Cutting at 90° (Straight Cut): 3-1/8" x 4-5/8"

  • Rectangular Tube Cutting at 45° Right: 3-1/8" x 3-1/8"

  • Rectangular Tube Cutting at 45° Left: 3-1/8" x 3-1/8"

NEW 350 EDV COLD SAW SPECIFICATIONS:

¢â‚¬â€ Blade Size Used: 350 x 2.5 x 32mm Bore HSS Blade

¢â‚¬â€ Cost Per 350mm Blade: $120 Each

¢â‚¬â€ 2 Speeds: 40 & 80 R.P.M.

¢â‚¬â€ Weight: 510 lbs. (231 kg.)

¢â‚¬â€ Maximum Vice Opening: 4.7¢â‚¬Â (120mm)

¢â‚¬â€ Overall Dimensions: 58¢â‚¬Â Width x 40¢â‚¬Â Length x 48¢â‚¬Â Height (1475 x 1000 x 1200 mm)
