Quantum Machinery 14" Manual, Double-Column Cold Saw (4-5/8" Round Tube Capacity)
The Quantum Macc NTM 350 Manual Cold Saw has a moveable head that can move up to 45 degrees left and 60 degrees right; and the head also has rotation stops at 45° - 0° - 45° - 60°. The NTM 350 has a vice that is complete with an anti-burr device, motor pump for blade lubrication, shave breaker to keep the blade clean. This unit is equipped with a a 1 meter long bar stop, 1 meter long bar support arm, and service tools, as well as the machine's manual and steel pedestal.
-
2 Speeds: 36 - 72 R.P.M. (Saw can be equipped with Variable Speed Inverter)
-
Weight: 993 lbs. (450 kg.)
-
Maximum Vice Opening: 7.2¢â‚¬Â (185mm)
-
Overall Dimensions: 42¢â‚¬Â Width x 40¢â‚¬Â Length x 73¢â‚¬Â Height (1050 x 1000 x 1850 mm)
-
The NTM 350 is to be equipped with a 350 x 2.5 x 32mm Bore HSS Blade
Options (Options are at an additional cost):
-
(+$600) Equip the NTM 350 with an Air Vice
-
(+$1,100) Equip the NTM 350 with a Variable Speed Inverter
NTM 350 COLD SAW CUTTING CAPACITIES:
Round Tube Cutting Capacities:
-
Round Tube Cutting at 90° (Straight Cut): 4-5/8"
-
Round Tube Cutting at 45° Left: 4-5/8"
-
Round Tube Cutting at 45° Right: 4-5/8"
-
Round Tube Cutting at 60° Right: 3-1/2"
Square Tube Cutting Capacities:
-
Square Tube Cutting at 90° (Straight Cut): 3-7/8"
-
Square Tube Cutting at 45° Left: 3-1/2"
-
Square Tube Cutting at 45° Right: 3-1/2"
-
Square Tube Cutting at 60° Right: 3-1/2"
Solid Round Cutting Capacities:
-
Solid Round Cutting at 90° (Straight Cut): 3-7/8"
-
Solid Round Cutting at 45° Left: 3-7/8"
-
Solid Round Cutting at 45° Right: 3-7/8"
-
Solid Round Cutting at 60° Right: 3-1/2"
Rectangular Tube Cutting Capacities:
-
Rectangular Tube Cutting at 90° (Straight Cut): 3-1/2" x 6-5/8"
-
Rectangular Tube Cutting at 45° Left: 3-1/2" x 4-7/8"
-
Rectangular Tube Cutting at 45° Right: 3-1/2" x 4-7/8"
-
Rectangular Tube Cutting at 60° Right: 3-1/2" x 3-1/2"
NTM 350 COLD SAW SPECIFICATIONS:
¢â‚¬â€ Blade Size Used: 350 x 2.5 x 32mm Bore HSS Blade
¢â‚¬â€ Cost Per 350mm Blade: $120 Each
¢â‚¬â€ 2 Speeds: 36 & 72 R.P.M.
¢â‚¬â€ Weight: 993 lbs. (450 kg.)
¢â‚¬â€ Maximum Vice Opening: 7.2¢â‚¬Â (185mm)
¢â‚¬â€ Overall Dimensions: 42¢â‚¬Â Width x 40¢â‚¬Â Length x 73¢â‚¬Â Height (1050 x 1000 x 1850 mm)
