KS 600

Double mitering 60 degrees left and 60 degrees right.

Canted sawframe canted 6 degrees

Semi-automatic horizontal bandsaws allow quick and easy setup and operation. Major components are mas-sive for solid, vibration-free production cutting. Machine operation is full cycle, semi-automatic. Material size is automatically sensed by the sawframe. With the push of a single button, the vise clamps, sawframe makes the cut at preset rate, automatically returns to clear work piece, vise opens, ready for the next cut. Production sawing can be very fast! Fully hydraulic, with free-standing op-erators console that may be conveniently placed in the most advantageous operator location.

Mitering is effortless with perfectly counterbalanced frame on bearings.

Material sensor, saw will rapid down until it touches ma-terial then go into controlled rate. After cut is complete the sawhead will lift to just above the material ready for the next cut.

Carbide guides w/ rollers

Standard Equipment

One Bi-metal sawblade

Low voltage control

TEFC 3 phase drive motor

Totally enclosed worm gear transmission

Full Coolant System

Full Blade Guarding

Operators Manual Parts List/Schematics

Tool kit

Capacities and Specifications

Capacities shown are max envelope. Each individual cutting job must be considered with regards to type and shape of material, and quantity of pieces per day.

(see chart in pictures)

Optional Accessories

AC600 10' Conveyor

AC625 5' Conveyor with coolant tray

AC116 Spray mist coolant
